Description

The compact master level converter UART (TTL) to M-Bus for THT mounting.

To be mounted on a base board by simple pin headers
Power supply: 24 VDC
M-Bus voltages are generated directly on the module
Galvanic isolation
Short-circuit protection

You can find a concrete recommendation for the use of our MBUS-M13-S by Texas Intruments. Here you can see a section of the application note.

Downloads

Here are our documents for download:

user manual MBUS-M13 pdf | 3,21 MB Ausschnitt der Applikationsschrift von Texas Instruments pdf | 108,31 KB Data sheet MBUS-M13 pdf | 758,63 KB
